Garbage from the sending tank flows directly into the Automatic Bag Breaking Sorting Equipment through a spiral conveyor or lift barrel. This system effectively processes unclassified or partially sorted kitchen waste, ensuring smooth and efficient sorting.
How the Sorting Process Works:
- Garbage Input: Kitchen waste enters the system via a spiral conveyor or lift barrel for further processing.
- Bag Breaking: The equipment breaks garbage bags automatically, exposing their contents for separation.
- Material Separation: High-speed rotation separates non-degradable inorganic materials from organic waste.
- Inorganic Waste Removal: Non-degradable materials slide out through a chute and move to the trash bin.
- Organic Waste Crushing: The system crushes organic waste into smaller pieces, reducing them to sizes below 40mm (or 25mm for kitchen waste).
- Final Discharge: Crushed organic material passes through a sieve and travels along a spiral conveyor to the discharge port.
The Automatic Bag Breaking Sorting Equipment provides a seamless, reliable, and eco-friendly solution for managing kitchen waste. Its advanced design minimizes manual effort, improves efficiency, and ensures precise separation of waste materials.
Specification and Parameter
| 1 | model：TJZJseries | 6 | Water out of water: gravity self -current, no special corrosive liquid |
| 2 | Medium: kitchen/kitchen waste/fruit and vegetable garbage | 7 | Ambient temperature：≥0~40℃ |
| 3 | Rated processing volume：1500-3000kg/h(Kitchen waste);
3000-6000kg/h(Kitchen) | 8 | Installation requirements: flat, ≥500mm space, more than 1.5m from fire source |
| 4 | Material: main body 304, bracket carbon steel anti -corrosion corrosion | 9 | Federation particle size: P≤25mm (kitchen), φ ≤40mm (kitchen waste) |
| 5 | Body weight：2000-3200kg | 10 | Total installed power：15.5-26kW |
